GU 3000

Product Information: The GU 3000 is a competitively priced dual spindle, 3 hook, 4 roller door lock with narrow spaced hooks. Operation: Lift lever or double spindle nightlatch. Latch reversal: Undo the screw in the latch to remove. Reverse, reinsert and replace screw. Specifications Centres: 92mm/62mm Length: 2150mm Backset: 35mm Case height: 230mm Case depth: Backset + 15mm Distance between outer rollers: 1680mm Distance between inner rollers: 940mm Distance between hooks: 1485mm
